All technical data presented represent typical results, unless stated otherwise as min/max values.
No guarantee is made that material will meet exactly the values shown.

Single Crystal Magnesium Oxide (MgO) [99.9%]



       Cubic

       0.4213nm

       Arc Melting Technology

       3.58 g/cm3

       2800 oC

       5.8

       12.80 x 10-6 / oC

       9.8

       Colorless




TEST 1 (Unit:ppm)
Material : Magnesium Oxide (MgO) Single Crystal
by Andong National University
Test method : ICP/AES at the room temperature

Test Result

Content Block Length B Mg Si Ca Fe Al2O3
No. 4 85mm 7.31 99.95 6.92 204.40 48.05 54.72
No. 5 90mm 7.50 99.96 5.61 189.25 41.29 53.52
No. 6 39mm 7.31 99.96 8.18 201.58 40.12 38.29
No. 9 60mm 7.01 99.95 7.55 207.38 52.32 38.58
No. 10 42mm 5.34 99.96 7.28 188.64 56.84 41.47

Remark
1. Tested all blocks are >42mm x 42mm size in dimension.



Application: Advanced ceramics, Specialty materials
Product type: Consumables, Chemicals
Production scale: Lab, Pilot, Commercial
Search tags: Advanced Ceramics, MgO, Single crystal, Deposition
